Hyperparameter Optimization of a Neural Network
Note
You can find the corresponding Python script here:
https://github.com/Helmholtz-AI-Energy/propulate/blob/master/tutorials/torch_example.py
Almost all machine-learning algorithms have non-learnable hyperparameters that influence the training and in
particular their predictive capacity.
Propulate is intended to help AI practitioners optimizing those hyperparameters efficiently on a large scale. Below,
we show you how to do this using a simple toy example. We want to train a simple convolutional neural network in Pytorch and
Pytorch-Lightning for MNIST classification and we want to know the best hyperparameters in terms of prediction
accuracy of our network for this.
The MNIST dataset. The MNIST dataset is a large collection of handwritten digits from 0 to 9.
We consider:
the number of convolutional layers
conv_layersthe activation function
activationthe learning rate
learning_rate
Thus, our search space dictionary looks as follows:
limits = {
"conv_layers": (2, 10), # Number of convolutional layers, int for ordinal
"activation": ("relu", "sigmoid", "tanh"), # Activation function, str for categorical
"learning_rate": (0.01, 0.0001), # Learning rate, float for continuous
}
When tuning an ML model’s hyperparameters, evaluating an individual during the optimization corresponds to training
a neural network instance using a specific combination of hyperparameters to be optimized. In addition, we need some
model performance metric to assign each evaluated individual, i.e., tested hyperparameter combination, a scalar loss.
We choose the model’s (negative) validation accuracy for this. Remember that the Propulate loss function takes
in a combination of those parameters that we want to optimize and returns a scalar value telling us how good this
parameter combination actually was. For hyperparameter optimization, the loss function thus takes in a hyperparameter
combination of our model, trains the model using this specific hyperparameter combination, and returns its (negative)
validation accuracy as a loss for the evolutionary optimization.
Below, we show you how to do this using the example of the most important code snippets. The lines directly related to
the hyperparameters we want to optimize are highlighted in pink. We start with defining the neural network which looks like this:
class Net(LightningModule):
"""
Neural network class.
Attributes
----------
best_accuracy : float
The model's best validation accuracy.
conv_layers : torch.nn.modules.container.Sequential
The model's convolutional layers.
fc : torch.nn.modules.linear.Linear
The model's fully connected layers.
loss_fn : torch.nn.modules.loss
The loss function used for training the model.
lr : float
The learning rate.
train_acc : torchmetrics.classification.accuracy.Accuracy
The accuracy metric used for evaluating model performance on the training dataset.
val_acc : torchmetrics.classification.accuracy.Accuracy
The accuracy metric used for evaluating model performance on the validation dataset.
Methods
-------
forward()
The forward pass.
training_step()
Calculate loss for training step in Lightning train loop.
validation_step()
Calculate loss for validation step in Lightning validation loop during training.
configure_optimizers()
Configure the optimizer.
on_validation_epoch_end()
Calculate and store the model's validation accuracy after each epoch.
"""
def __init__(
self,
conv_layers: int,
activation: torch.nn.modules.activation,
lr: float,
loss_fn: torch.nn.modules.loss,
) -> None:
"""
Set up neural network.
Parameters
----------
conv_layers : int
The number of convolutional layers.
activation : torch.nn.modules.activation
The activation function to use.
lr : float
The learning rate.
loss_fn : torch.nn.modules.loss
The loss function.
"""
super().__init__()
self.lr = lr # Set learning rate.
self.loss_fn = loss_fn # Set the loss function used for training the model.
self.best_accuracy = 0.0 # Initialize the model's best validation accuracy.
layers = (
[]
) # Set up the model architecture (depending on number of convolutional layers specified).
layers += [
nn.Sequential(
nn.Conv2d(in_channels=1, out_channels=10, kernel_size=3, padding=1),
activation(),
),
]
layers += [
nn.Sequential(
nn.Conv2d(in_channels=10, out_channels=10, kernel_size=3, padding=1),
activation(),
)
for _ in range(conv_layers - 1)
]
self.fc = nn.Linear(in_features=7840, out_features=10) # MNIST has 10 classes.
self.conv_layers = nn.Sequential(*layers)
self.val_acc = Accuracy("multiclass", num_classes=10)
self.train_acc = Accuracy("multiclass", num_classes=10)
def forward(self, x: torch.Tensor) -> torch.Tensor:
"""
Forward pass.
Parameters
----------
x : torch.Tensor
The data sample.
Returns
-------
torch.Tensor
The model's predictions for input data sample.
"""
b, c, w, h = x.size()
x = self.conv_layers(x)
x = x.view(b, 10 * 28 * 28)
x = self.fc(x)
return x
def training_step(
self, batch: Tuple[torch.Tensor, torch.Tensor], batch_idx: int
) -> torch.Tensor:
"""
Calculate loss for training step in Lightning train loop.
Parameters
----------
batch : Tuple[torch.Tensor, torch.Tensor]
The input batch.
batch_idx : int
Its batch index.
Returns
-------
torch.Tensor
The training loss for this input batch.
"""
x, y = batch
pred = self(x)
loss_val = self.loss_fn(pred, y)
self.log("train loss", loss_val)
train_acc_val = self.train_acc(torch.nn.functional.softmax(pred, dim=-1), y)
self.log("train_ acc", train_acc_val)
return loss_val
def validation_step(
self, batch: Tuple[torch.Tensor, torch.Tensor], batch_idx: int
) -> torch.Tensor:
"""
Calculate loss for validation step in Lightning validation loop during training.
Parameters
----------
batch : Tuple[torch.Tensor, torch.Tensor]
The current batch
batch_idx : int
The batch index.
Returns
-------
torch.Tensor
The validation loss for the input batch.
"""
x, y = batch
pred = self(x)
loss_val = self.loss_fn(pred, y)
val_acc_val = self.val_acc(torch.nn.functional.softmax(pred, dim=-1), y)
self.log("val_loss", loss_val)
self.log("val_acc", val_acc_val)
return loss_val
def configure_optimizers(self) -> torch.optim.SGD:
"""
Configure the optimizer.
Returns
-------
torch.optim.sgd.SGD
A stochastic gradient descent optimizer.
"""
return torch.optim.SGD(self.parameters(), lr=self.lr)
def on_validation_epoch_end(self):
"""Calculate and store the model's validation accuracy after each epoch."""
val_acc_val = self.val_acc.compute()
self.val_acc.reset()
if val_acc_val > self.best_accuracy:
self.best_accuracy = val_acc_val
We also need some helper function to load the MNIST data:
def get_data_loaders(batch_size: int) -> Tuple[DataLoader, DataLoader]:
"""
Get MNIST train and validation dataloaders.
Parameters
----------
batch_size : int
The batch size.
Returns
-------
torch.utils.data.DataLoader
The training dataloader.
torch.utils.data.DataLoader
The validation dataloader.
"""
data_transform = Compose([ToTensor(), Normalize((0.1307,), (0.3081,))])
num_workers = NUM_WORKERS
log.info(f"Use {num_workers} workers in dataloader.")
if MPI.COMM_WORLD.rank == 0: # Only root downloads data.
train_loader = DataLoader(
dataset=MNIST(
download=True, root=".", transform=data_transform, train=True
), # Use MNIST training dataset.
batch_size=batch_size, # Batch size
num_workers=num_workers,
pin_memory=True,
persistent_workers=True,
shuffle=True, # Shuffle data.
)
MPI.COMM_WORLD.barrier()
if MPI.COMM_WORLD.rank != 0:
train_loader = DataLoader(
dataset=MNIST(
download=False, root=".", transform=data_transform, train=True
), # Use MNIST training dataset.
batch_size=batch_size, # Batch size
num_workers=num_workers,
pin_memory=True,
persistent_workers=True,
shuffle=True, # Shuffle data.
)
val_loader = DataLoader(
dataset=MNIST(
download=False, root=".", transform=data_transform, train=False
), # Use MNIST testing dataset.
num_workers=num_workers,
pin_memory=True,
persistent_workers=True,
batch_size=1, # Batch size
shuffle=False, # Do not shuffle data.
)
return train_loader, val_loader
Now we are ready to set up the Propulate loss function that is minimized during the evolutionary optimization in
order to find the best hyperparameters for our model:
def ind_loss(params: Dict[str, Union[int, float, str]]) -> float:
"""
Loss function for evolutionary optimization with Propulate. Minimize the model's negative validation accuracy.
Parameters
----------
params : Dict[str, int | float | str]
The hyperparameters to be optimized evolutionarily.
Returns
-------
float
The trained model's negative validation accuracy.
"""
# Extract hyperparameter combination to test from input dictionary.
conv_layers = params["conv_layers"] # Number of convolutional layers
activation = params["activation"] # Activation function
lr = params["lr"] # Learning rate
epochs = 100
activations = {
"relu": nn.ReLU,
"sigmoid": nn.Sigmoid,
"tanh": nn.Tanh,
} # Define activation function mapping.
activation = activations[activation] # Get activation function.
loss_fn = (
torch.nn.CrossEntropyLoss()
) # Use cross-entropy loss for multi-class classification.
model = Net(
conv_layers, activation, lr, loss_fn
) # Set up neural network with specified hyperparameters.
model.best_accuracy = 0.0 # Initialize the model's best validation accuracy.
train_loader, val_loader = get_data_loaders(
batch_size=8
) # Get training and validation data loaders.
tb_logger = loggers.TensorBoardLogger(
save_dir=log_path + "/lightning_logs"
) # Get tensor board logger.
# Under the hood, the Lightning Trainer handles the training loop details.
trainer = Trainer(
max_epochs=epochs, # Stop training once this number of epochs is reached.
accelerator="gpu", # Pass accelerator type.
devices=[MPI.COMM_WORLD.rank % GPUS_PER_NODE], # Devices to train on
callbacks=[EarlyStopping(monitor="val_loss", mode="min")],
enable_progress_bar=False, # Disable progress bar.
logger=tb_logger, # Logger
)
trainer.fit( # Run full model training optimization routine.
model=model, # Model to train
train_dataloaders=train_loader, # Dataloader for training samples
val_dataloaders=val_loader, # Dataloader for validation samples
)
# Return negative best validation accuracy as an individual's loss.
return -model.best_accuracy.item()
Just as before, this loss function is fed into the asynchronous evolutionary optimizer (Propulator) or the
asynchronous island model (Islands) which takes care of the actual genetic optimization.
if __name__ == "__main__":
comm = MPI.COMM_WORLD
num_generations = 10 # Number of generations
pop_size = 2 * comm.size # Breeding population size
limits = {
"conv_layers": (2, 10),
"activation": ("relu", "sigmoid", "tanh"),
"lr": (0.01, 0.0001),
} # Define search space.
rng = random.Random(
comm.rank
) # Set up separate random number generator for evolutionary optimizer.
propagator = get_default_propagator( # Get default evolutionary operator.
pop_size=pop_size, # Breeding population size
limits=limits, # Search space
crossover_prob=0.7, # Crossover probability
mutation_prob=0.4, # Mutation probability
random_init_prob=0.1, # Random-initialization probability
rng=rng, # Separate random number generator for Propulate optimization
)
# Set up separate logger for Propulate optimization.
set_logger_config(
level=logging.INFO, # Logging level
log_file=f"{log_path}/{pathlib.Path(__file__).stem}.log", # Logging path
log_to_stdout=True, # Print log on stdout.
log_rank=False, # Do not prepend MPI rank to logging messages.
colors=True, # Use colors.
)
# Set up propulator performing actual optimization.
propulator = Propulator(
loss_fn=ind_loss, # Loss function to optimize
propagator=propagator, # Evolutionary operator
rng=rng, # Random number generator
island_comm=comm, # Communicator
generations=num_generations, # Number of generations per worker
checkpoint_path=log_path, # Path to save checkpoints to
)
# Run optimization and print summary of results.
propulator.propulate(
logging_interval=1, debug=2 # Logging interval and verbosity level
)
propulator.summarize(
top_n=1, debug=2 # Print top-n best individuals on each island in summary.
)
After additionally installing torch, lightning, and tensorboard, we can use the the virtual environment from
the previous example to run a search with four GPUs on a single node:
$ source best-venv-ever/bin/activate
$ mpirun -N 4 python torch_example.py
Note
Running the script from our Github repo without any modifications requires compute nodes with four GPUs and a CUDA installation.
